Household Appliances Home Medical Industry Push Rod Motor Brush DC Motor
Product Details:
| Place of Origin: | Dongguan China |
| Brand Name: | UCHI |
| Certification: | Completed |
| Model Number: | DL-4230D24-MT001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard |
| Delivery Time: | 5-7 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000pcs stcoks |
|
Detail Information |
|||
| Rated Power: | 100W | Rated Current: | 4A |
|---|---|---|---|
| Boundary Dimension: | 59 | 3C Rated Voltage Range: | 12-48 |
| Rated Speed: | 3500 | Nominal Voltage: | 12-48 |
| Nominal Torque: | 0.4N.m | Range Of Application: | Furniture/medical/industry |
| With Inductance: | With Inductance | Shell: | Cold Drawing |
| Axle: | Wormwheel | Motor Name: | Brush DC Motors |
| Highlight: | DC push rod motor,Home medical industry push rod motor,Household appliances push rod motor |
||
Product Description
Household appliances Home medical industry push rod motor brush DC motor
| voltage | DC12-29V |
| power | 80W max |
| twisting force | 0.2N.m max |
| rotate speed | 8000 max |
| Hall | optional |
| gear ratio | Single/double head |
| external diameter | 59 |
| pushing force | 4000N Max |
