|Name:||Fast Blow Fast-acting Ceramic Fuse Holder For 10x38mm Cylindrical Fuses||Suitable:||10x38mm Cylindrical Fuses|
|Rated Volage:||600VAC / DC||Max. Current:||30A|
|Dielectric Strength:||>1200 V||Thermoplastic:||Meets UL94 V-0 Flammability Standards|
|Clip/terminals:||Tin-plated Copper Alloy||Screw And Captive Pressure Plate:||Zinc-plated Steel|
|Base Temperature:||125℃||Wire Range:||6-14 AWG|
|Torque:||4n.m (35 In-lbs)||MOQ:||1000PCS|
mini glass fuses,
radial lead fuse
ADLER BH112 Thermoplastic Fast Blow Fast-acting Ceramic Fuse Holder For 10x38mm Cylindrical Fuses
This BH112 holder made of thermoplastic is designed for 10x38mm cylindrical fuses and allows for easy mounting on flat surfaces. Please note, BH112 cannot be mounted on DINR constructions.
|Rated Voltage||600VAC / DC|
|Thermoplastic||meets UL94 V-0 flammability standards|
|Dielectric strength||more than 1200V|
|Clip/Terminal||Tin-plated copper alloy|
|Screw and captive pressure plate||Zin plate steel|
|Torque||4n.m (35 in-lbs)|
Dimension in mm
