BH100 BH101 10x38mm 1000VDC Ceramic Glass Fuses Holder With Indicator Light
Product Details:
| Place of Origin: | Germany/China |
| Brand Name: | ADLER |
| Certification: | ROHS etc. |
| Model Number: | BH100/BH101 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000PCS |
|---|---|
| Packaging Details: | Bulk |
| Delivery Time: | 4 weeks |
| Payment Terms: | Western Union, MoneyGram, T/T |
| Supply Ability: | 5000,000PCS/Month |
|
Detail Information |
|||
| Name: | 10x38mm Ceramic Glass Fuse Holder | Suitable: | 10x38mm Miniature Fuses |
|---|---|---|---|
| Rated Volage: | 1000 VDC/600VDC | Rated Current: | 0-50A |
| Withstand Rating, DC Amperes: | 30KA/10KA | Material Flammability: | UL 94-V0 (PBT)/ UL91-V2 (PA6) |
| Mounting: | DIN Rail Mounting | Wire Diameters: | 0.8mm² – 6.0mm² |
| Ambient Temperature: | -40°C ~ +130°C | Neon Light Indicator In Case Of Over-current Fault: | Min 90VAC |
| High Light: | slow blow glass fuse,radial lead fuse |
||
Product Description
DIN Rail Mounting BH100 BH101 10x38mm 1000VDC 0-50A 30KA Ceramic Glass Fuse Holder With Indicator Light
Ceramic Glass Fuse Holder With Indicator Light BH100&BH101_datasheet_20161112.pdf
Features
ADLER BH100 and BH101 holders are designed for A73 series and standard 10x38mm PV fuses. The
BH101 holder is equipped with a red indicator light. It will light up when the inserted fuse is blown.
Description
The BH100 and BH101 holder applies to 10x38mm fuse.
The BH100 holder without indicator light,BH101 holder with indicator light.
When the fuse burn-out the light will be light up.
Specifications
| Rated Voltage | 1000VDC/600VDC |
| Rated Current | 0-50A |
| Withstand rating,DC Amperes | 30KA/10KA |
| Material Flammability | UL 94-V0(PBT)/ UL91-VS(PA6) |
| Neon Light Indicator in case of over-current fault(optional) | min 90VAC |
| Mounting | DIN Rail mounting |
| Wire diameters | 0.8mm² – 6.0mm² |
| Ambient temperature | -40°C ~ +130°C |
Dimension in mm
Related Product Range
Environmental
About Manufacturer
Company Name: ADLER Elektrotechnik Leipzig GmbH
Location: Leipzig, Saxony, Germany
Expertise: Design, Marketing and Sales of electrical, EV and Photovoltaic protection
Our product range includes:
- Low voltage fuses
- NH blade fuses for general industrial application (gG)
- Medium voltage fuses up to 36kV
- Power protection solutions
- Photovoltaic midget and medium fuse links
- Photovoltaic NH fuses in various sizes (gPV)
- PV Surge Protection Devices (SPD)
- PV Combiner Boxes and Parts
- Fuse holders, mounting bases
Across all of our product range, we are proud to represent established, certified products that have developed a reputation for quality, reliability and innovation. Please refer to our brand and datasheets available from our website for a more detailed overview of our products.
We provide our customers with solutions expertise, a high standard of personalized service, availability of stock and an 'easy to deal with' experience.
Our Mission:
We add value to our customer's business by supplying quality specialist electrical products, solutions-focused expertise, personal service and genuine customer care at highest possible standards in our industry.
