30W Tubular Heat Sink Anodized Skived Heat Sink
Product Details:
| Place of Origin: | Dongguan，Guangdong,China |
| Brand Name: | Uchi |
| Certification: | SMC |
| Model Number: | Cold Forged Heat Sink 08 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | Negotiable |
| Payment Terms: | T/T，paypal， Western Union,MoneyGram |
| Supply Ability: | 50000000pcs per Month |
|
Detail Information |
|||
| Body Material: | Aluminum | Temper: | T3~T8 |
|---|---|---|---|
| Surface Treatment: | Anodized | Tolerance: | ±1% |
| Material: | Aluminum 1070 (99.5%) | IP Rating: | IP67 |
| Thickness: | 0.30mm--Customized | Weight: | 0.75 Kg |
| Watts: | 45-75 Watts | Body Color: | Black |
| Highlight: | 30W tubular heat sink,anodized skived heat sink,liquid cooling plate heat sink |
||
Product Description
30W Tubular Heat Sink - Anodized Skived Heat Sink
45-75W Round Pin Fin Anodized Aluminum Cold Forged Heat Sink designed for optimal thermal performance in LED grow light applications.
Key Features
- Easy installation with comprehensive tutorials for DIY LED grow light assembly
- Standard product range from 40W to 500W with professional thermal analysis, CAD design, and technical support
- Complete LED grow lighting accessories available in one-stop solution
- Special aluminum brackets and fasteners for professional system integration
- 5-year warranty with complete quality management system and comprehensive after-sales service
Application Examples
Example 1: Single 75-90 Watts
- Top Bin CXB3590/Vero29/CLU048 + Driver: MW HBG-100-48A
- Flower Coverage Area: < 4 Square Feet, Veg Coverage Area: ~3 Square Feet
Example 2: Rapid LED Grow Light 100-120 Watts
- 2 x Top Bin CXB3590/Vero29/CLU048 + Driver: MW HLG-185H-C1400B
- Aluminum profiles fixture
- Veg Coverage Area: 6.5-8.3 Square Feet
Example 3: Rapid LED Grow Light 315-375 Watts
- 5 x Top Bin CXB3590/Vero29/CLU048 + Driver: MW HLG-185H-C1400B
- Aluminum profiles fixture
- Veg Coverage Area: 6.5-8.3 Square Feet
Product Specifications
| Material | Aluminum 1070 (99.5%) |
| Watts | 45-75 Watts |
| Weight | 0.723 kg |
| Packing Detail | 1 Pieces /Box |
| Delivery Time | 7-10 days after order confirmed |
| Certificates | ISO 9001:2015 / SGS |
| Application | LED Grow Light |
Heat Sink Drawing
Pre-drilled for CXB 3590/Vero29/CLU-048/CXM-22 COB. Custom specifications available upon request.
Advantages of Cold Forging: No black scale remains at the root of the pillars after CNC machining.
Disadvantages of Hot Forging: Large areas of black scale are left at the root of the pillars after CNC machining.
Main Manufacturing Processes of Cold Forged Heat Sinks
Industry Applications
- New Energy Vehicle Sector: Motor/Electronic Control System, Battery Pack System, Charging Pile Module
- Industrial High-power Equipment Sector: Frequency Converter/Servo System, High-power Power Supply, Laser Equipment
- Consumer Electronics and High-end Equipment Sector: High-performance Consumer Electronics, Aerospace Equipment
- New Energy Energy Storage Sector
Advanced Equipment & Precision Machining
Our mold workshop features comprehensive manufacturing capabilities including:
- 22 sets of electric discharge machines (EDM) including 2 MAKINO mirror EDM machines
- 9 wire-cut EDM machines (low-speed) with 3 Seibu and 1 Sodick imported from Japan
- 7 spark erosion machines, 10 grinding machines, 2 milling machines, and 1 lathe
| Table Size | 500×350 mm |
| Rapid Traverse Speed | 5000 mm/min |
| Maximum Workpiece Weight | 500 kg |
| Maximum Electrode Weight | 50 kg |
High Machining Precision: Utilizing SuperSpark4 and IES (Intelligent Expert System) technologies for advanced adaptive power supply and jump control to stabilize EDM processes and improve precision. Equipped with ultra-surface and ultra-edge generator technologies for excellent surface finish and metallurgical quality.
Quality Assurance
We maintain rigorous quality standards with comprehensive testing equipment:
- 1 Coordinate Measuring Machine
- 1 projector instrument
- 2 water high pressure testing machines
- 4 thermal resistance testing machines
- 2 liquid leakage testing machines
Customer Service Commitment
- Prompt response to all inquiries
- Competitive pricing with guaranteed quality
- Efficient production scheduling
- Optimal transportation solutions
- Comprehensive technical support
Frequently Asked Questions
Are you a trading company or manufacturer?
We are a professional manufacturer of heat sinks and water cooling plates with extensive experience and a strong technical team, featuring automated and mechanized production.
We are a professional manufacturer of heat sinks and water cooling plates with extensive experience and a strong technical team, featuring automated and mechanized production.
Have you exported goods before and to which regions?
60% of our total production is exported to Japan, India, UK, Canada, USA, and Brazil.
60% of our total production is exported to Japan, India, UK, Canada, USA, and Brazil.
How many employees do you have?
Approximately 100 employees across sales, purchasing, engineering, QA, warehouse, and production departments.
Approximately 100 employees across sales, purchasing, engineering, QA, warehouse, and production departments.
Can you provide samples if we agree with the design?
Yes, we provide samples for confirmation before mass production, along with technical drawings if required.
Yes, we provide samples for confirmation before mass production, along with technical drawings if required.
What packing methods do you use?
Customized packing with normal cartons and tight-proof fabric or wooden cartons for optimal protection during transportation.
Customized packing with normal cartons and tight-proof fabric or wooden cartons for optimal protection during transportation.
Do you provide technical support for product issues?
All products are fully inspected before shipping. For any issues, we provide immediate technical solutions.
All products are fully inspected before shipping. For any issues, we provide immediate technical solutions.
