ESD Protection ICs 5V Bidirectional ESDand Surge Protection Device
Product Details:
| Place of Origin: | Dongguan China |
| Brand Name: | UCHI |
| Certification: | Completed |
| Model Number: | SGM05HB1AM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard |
| Delivery Time: | 3weeks |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 5000pcs |
|
Detail Information |
|||
| Peak Pulse Current (tP = 8/20μs): | 30A | ESD IEC 61000-4-2 (Air): | ±30kV |
|---|---|---|---|
| ESD IEC 61000-4-2 (Contact): | ±30kV | Operating Temperature Range: | -40 To +125℃ |
| Storage Temperature Range: | -55 To +150℃ | Lead Temperature (Soldering, 10s): | +260℃ |
| Highlight: | 5V bidirectional ESD protection IC,surge protection device with ESD,high power MOSFET protection IC |
||
Product Description
ESD Protection ICs 5V Bidirectional ESDand Surge Protection Device
The SGM05HB1AM is designed to protect voltagesensitive components from ESD. Excellent clampingcapability, low leakage, high peak pulse currenthandling capability and fast response time provide bestin class protection on designs that are exposed to ESD.Because of its small size, it is suited for use in cellularphones, tablets, digital cameras and many other portableapplications where board space comes at a premium.
Key Features
● Low Clamping Voltage
● Low Leakage
● Small Package: UTDFN-1×0.6-2AL
● Protection for the Following IEC Standards:IEC 61000-4-2 Level 4: ±30kV Contact DischargeIEC 61000-4-5 (Lightning) 30A (8/20μs)
● These Devices are Pb-Free, Halogen Free/BFRFree and are RoHS Compliant
Applications
Battery Line Protection
Audio Line Protection
GPIO
Audio Line Protection
GPIO
Pin Configurations
Product Selection Guid
| Channel | Part Number |
Configuration
|
VRWM
Max
(V)
|
IPPM
Max
(A)
|
CIN Typ (pF)
|
Packag
|
Features |
|---|---|---|---|---|---|---|---|
| 1 | SGM05CB1A4 |
Bidirectional
|
5 | 4 | 2.7 |
UTDFN-1×0.6-2L,XTDFN-0.6×0.3-2L
|
Low Capacitance, 1-Channel ESD Protection
|
| 1 | SGM05CB1A7 |
Bidirectional
|
5 | 7 | 9 |
X4DFN-0.63×0.33-2L
|
Low Capacitance, 1-Channel ESD Protection
|
| 1 | SGM05CB1A8 |
Bidirectional
|
5 | 8.5 | 9.6 |
UTDFN-1×0.6-2L
|
Low Capacitance, 1-Channel ESD Protection
|
| 1 | SGM05FB1E2 |
Bidirectional
|
5 | 2.4 | 0.3 |
UTDFN-1×0.6-2L,XTDFN-0.6×0.3-2L
|
Femto-Farad Capacitance, 1-Channel ESD Protection
|
| 2 | SGM05FB2E2 |
Bidirectional
|
5 | 2.5 | 0.3 |
UTDFN-1×0.6-3L
|
Femto-Farad Capacitance, 2-Channel ESD Protection
|
| SGM05HB1AM |
Bidirectional
|
4.8/5.5 | 30 | 36 |
UTDFN-1×0.6-2AL
|
5V Bidirectional ESD and Surge Protection Device
|
|
| 1 | SGM05UB1B3 |
Bidirectional
|
5 | 4.2 | 0.5 |
UTDFN-1×0.6-2L,XTDFN-0.6×0.3-2L
|
Ultra-Low Capacitance, 1-Channel ESD Protection
|
| 1 | SGM12CB1A5 |
Bidirectional
|
12 | 5 | 1 |
UTDFN-1×0.6-2L
|
Low Capacitance, 1-Channel ESD Protection
|
| 1 | SGM12UB1D2 |
Bidirectional
|
12 | 2 | 0.35 |
UTDFN-1×0.6-2L,XTDFN-0.6×0.3-2L
|
Ultra-Low Capacitance, 1-Channel ESD Protection
|
| 1 | SGM15CB1A4 |
Bidirectional
|
15 | 4 | 1 |
UTDFN-1×0.6-2L
|
Low Capacitance, 1-Channel ESD Protection
|
| 1 | SGM15UB1E2 |
Bidirectional
|
15 | 2 | 0.35 |
UTDFN-1×0.6-2L,XTDFN-0.6×0.3-2L
|
Ultra-Low Capacitance, 1-Channel ESD Protection
|
