1.5A, 7.5V H-Bridge Driver For Motor/Coil Integrated Circuit IC Chip
Product Details:
| Place of Origin: | Dongguan China |
| Brand Name: | UCHI |
| Certification: | Completed |
| Model Number: | SGM42507 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard |
| Delivery Time: | 3weeks |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 5000pcs |
|
Detail Information |
|||
| VCC: | -0.3V To 9V | Digital Input Pin Voltage Range: | -0.3V To 6V |
|---|---|---|---|
| SC70-6, θJA: | 245.8℃/W | TSOT-23-6, θJA: | 217.8℃/W |
| Junction Temperature: | +150℃ | Storage Temperature Range: | -65 To +150℃ |
| Lead Temperature (Soldering, 10s): | +260℃ | HBM: | 5000V |
| CDM: | 1000V | MM: | 300V |
| Highlight: | 1.5A H-Bridge motor driver IC,7.5V motor control integrated circuit,H-Bridge driver chip for coils |
||
Product Description
1.5A, 7.5V H-Bridge Driver For Motor/Coil Integrated Circuit IC Chip
The SGM42507 is an integrated driver IC for drivingmotors and coils in industrial applications. The PH andEN/FAULT pins allow simple interfacing to controllercircuits.
Internal protection functions are provided for undervoltage lockout (UVLO), over-current protection (OCP)and over-temperature protection (OTP). Faultconditions are indicated by the EN/FAULT pin.
The SGM42507A is available in a Green TSOT-23-6package. The SGM42507B/C are available in GreenSC70-6 and TSOT-23-6 packages. They operate overan ambient temperature range of -40℃ to +125℃.
Internal protection functions are provided for undervoltage lockout (UVLO), over-current protection (OCP)and over-temperature protection (OTP). Faultconditions are indicated by the EN/FAULT pin.
The SGM42507A is available in a Green TSOT-23-6package. The SGM42507B/C are available in GreenSC70-6 and TSOT-23-6 packages. They operate overan ambient temperature range of -40℃ to +125℃.
Key Features
● Internal OC/UV/OT Protections
Over-Current Threshold Options:0.45A/0.9A/1.5A
Under-Voltage Threshold Options:1.75V/2.8V/3.6V
Over-Temperature Protection
● Up to 7.5V Supply Range for ApplicationsPowered by:
1 Li+/Poly Cell 2/3/4 Dry Cells
1/2 LiSOCl2 Cell(s)
● Selectable Slow or Fast Decay Modes
● -40℃ to +125℃ Operating Temperature Range
● SGM42507A is Available in a Green TSOT-23-6PackageSGM42507B/C are Available in Green SC70-6 andTSOT-23-6 Packages
Applications
Robot
Utility Meter
Solenoid
Utility Meter
Solenoid
Typical Application
Pin Configurations
Pin Description
Product Selection Guid
Pin Configurations
Pin Description
Product Selection Guid
| Part Number |
Full Bridges
per
Package
|
Motor Type
|
VCC
Min
(V)
|
VCC
Max
(V)
|
RMS
Output Current
(A)
|
Peak
Output Current
(A)
|
Control
Interface
|
RDS(ON)
(HS+LS) per Channel
(mΩ)
|
Operating
Temperature
Range (℃)
|
Packag
|
Features |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SGM42500
|
1 |
DC Motor
|
7
|
40 | 3.6 |
PWM
|
410
|
-40 to +125
|
SOIC-8 (Exposed Pad)
|
3.6A Brushed DC Motor Driver
|
|
|
SGM42501
|
1 |
DC Motor
|
7
|
40 | 3.6 |
PH/EN
|
410
|
-40 to +125
|
SOIC-8 (Exposed Pad)
|
3.6A Brushed DC Motor Driver
|
|
|
SGM42505
|
1 |
DC Motor
|
7
|
40 | 3.6 |
PWM
|
410
|
-40 to +125
|
SOIC-8 (Exposed Pad)
|
3.6A Brushed DC Motor Driver
|
|
|
SGM42506
|
1 |
DC Motor
|
7
|
40 | 3.6 |
PH/EN
|
410
|
-40 to +125
|
SOIC-8 (Exposed Pad)
|
3.6A Brushed DC Motor Driver
|
|
|
SGM42507
|
1 |
DC Motor
|
1.9
|
7.5 | 1.5 |
PH/EN
|
555 |
-40 to +125
|
SC70-6,TSOT-23-6
|
1.5A, 7.5V H-Bridge Driver for Motor/Coil
|
|
|
SGM42512
|
1 |
DC Motor
|
1.9
|
5.5 | 1.5 |
PH/EN
|
545 |
-40 to +125
|
TSOT-23-6 |
Single H-Bridge Motor Driver
|
|
|
SGM42513
|
1 |
DC Motor
|
1.9
|
5.5 | 1.5 | PWM | 545 |
-40 to +125
|
TSOT-23-6 |
Single H-Bridge Motor Driver
|
|
|
SGM42540
|
1 |
DC Motor
|
8
|
45 | 3.5 | 4.5 |
PH/EN
|
210
|
-40 to +85
|
TSSOP-28 (Exposed Pad)
|
Single H-Bridge DC Motor Driver
|
|
SGM42609
|
1 |
DC Motor
|
2.7 | 24 | 1.5 | 2 | PWM | 480 | -40 to +125 |
MSOP-10,TDFN-3×3-10L
|
Single H-Bridge Motor Driver |
|
SGM42541
|
2 |
DC/Stepper Motor
|
8
|
45 | 2 | PWM | 420 | -40 to +85 |
TSSOP-28 (Exposed Pad)
|
Dual H-Bridge Driver
|
|
|
SGM42544
|
4 Half
|
DC/Stepper Motor
|
8
|
45 | 1.75 | 2 |
EN/IN
|
440 | -40 to +125 |
TSSOP-28 (Exposed Pad)
|
Quad Half-Bridge Driver
|
|
SGM42600
|
2 |
DC/Stepper Motor
|
2.7 | 24 | 1.5 | 2 | PWM | 410 | -40 to +125 |
TSSOP-16 (Exposed Pad),TQFN-4×4-16L
|
Dual H-Bridge Motor Driver
|
|
SGM42610
|
2 |
DC/Stepper Motor
|
2.5
|
16 | 0.85 | 1.2 |
4×PWM
|
1540
|
-40 to +85 |
MSOP-10 (Exposed Pad),SSOP-10
|
Stepper Motor Driver
|
|
SGM42611A
|
2 |
DC/Stepper Motor
|
2.5
|
16 | 0.85 | 1.2 |
4×PWM
|
1540
|
-40 to +85 |
MSOP-10 (Exposed Pad),SSOP-10
|
Stepper Motor Driver
|
|
SGM42611B
|
2 |
DC/Stepper Motor
|
2.5
|
16 | 0.85 | 1.2 |
2×PWM
|
1540
|
-40 to +85 |
MSOP-10 (Exposed Pad),SSOP-10
|
Stepper Motor Driver
|
|
SGM42633
|
2 |
DC/Stepper Motor
|
2.5
|
12 | 0.6 | 1 | PWM |
1610
|
-40 to +125 |
TSSOP-16 (Exposed Pad),TQFN-3×3-16L
|
Dual H-Bridge Motor Driver
|
|
SGM42606
|
1 |
DC Motor
|
2 | 12 | 3 | 6 | PWM | 72 | -40 to +85 |
TQFN-5.5×3.5-24L
|
H-Bridge Motor Driver
|
|
SGM42622B
|
2 |
Stepper Motor
|
1.8 | 12 | 1.3 | 2 |
STP/DIR
|
500 | -40 to +85 |
TQFN-3×3-16L
|
Stepper Motor Driver with 1/256 Micro-Stepping
|
