12-Input, 9-Output Video Switch Matrix With Output Drivers, Input Clamp,and Bias Circuitry Integrated Circuit IC
Product Details:
| Place of Origin: | Dongguan China |
| Brand Name: | UCHI |
| Certification: | Completed |
| Model Number: | SGM6501 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard |
| Delivery Time: | 3weeks |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 5000pcs |
|
Detail Information |
|||
| Supply Voltage Range (DC): | -0.3V To 6V | Analog And Digital Input/Output Voltage Range: | -0.3V To VCC + 0.3V |
|---|---|---|---|
| Output Current Per Channel: | 40mA (MAX) | Junction Temperature: | +150℃ |
| Storage Temperature Range: | -65℃ To +150℃ | Lead Temperature (Soldering, 10s): | +260℃ |
| HBM (SSOP-28): | 8000V | HBM (TSSOP-28): | 7000V |
| CDM: | 2000V | MM: | 400V |
| Highlight: | 12-input video switch matrix IC,9-output video switch with drivers,integrated circuit with bias circuitry |
||
Product Description
12-Input, 9-Output Video Switch Matrix With Output Drivers, Input Clamp,and Bias Circuitry Integrated Circuit IC
The SGM6501 is a video switch matrix which features12 input channels and 9 output channels. Thearchitecture allows any of the 12 inputs to be routed toany of the 9 outputs, and it supports one input to oneoutput or one input to more outputs switching. Therouting map is configured by I2C-compatible serialinterface.The SGM6501 has the input clamp function and biascircuitry, the input clamp or bias mode is selectablethrough I2C interface. Integrated clamp is supported byeach input. The function is to set video output synclevel to approximately 600mV. If sync signal (Chroma,Pb, Pr) is absent, the input is biased by approximately1.3V, which is the center of input voltage range.The SGM6501 is available in Green SSOP-28 andTSSOP-28 packages. It operates over an ambienttemperature range of -40℃ to +85℃.
Key Features
● Single-Supply Voltage Range: 3.1V to 5.5V
● 12 × 9 Crosspoint Switch Matrix
● Supports Standard Definition (SD), ProgressiveScan (PS), and High Definition (HD) Video
● -3dB Bandwidth: 84MHz
● Low Crosstalk: -74dB at 1MHz
● Programmable Gain Options:6dB, 7dB, 8dB, or 9dB
● Input Bias Circuitry and Input Clamp Function
● Supports I2C Serial Interface
● Double-Load 75Ω Output Drivers
● AC- or DC-Coupled Inputs and Outputs
● Available in Green SSOP-28 and TSSOP-28Packages
Applications
Security and Surveillance
TV and HDTV
Automotive Entertainment System
Media Centers
Video Routing
Cable and Satellite Set-Top Boxes
TV and HDTV
Automotive Entertainment System
Media Centers
Video Routing
Cable and Satellite Set-Top Boxes
Pin Configurations & Pin Description
Product Selection Guide
| Part Number | Type |
Vcc
(V)
|
Bandwidth
@-3dB
(MHz)
|
Control
Interface
|
RON
(Ω)
|
RON
Flatness
(Ω)
|
CON
(pF)
|
COFF
CS/CD
(pF)
|
Crosstalk
Typ
(dB)
|
Charge Injection
Typ
(pC)
|
Package
|
Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SGM6501 | 12×9 | 3.1~5.5 | 84 |
I2C |
-74 |
SSOP-28,TSSOP-28
|
12×9, Buffered
|
|||||
| SGM6502 | 8×6 | 3.1~5.5 | 88 |
I2C |
-77 |
TSSOP-24
|
8×6, Buffered
|
|||||
| SGM6503 | 1.8~5.5 | 400 |
I/O |
3.5/0.45 | 12/185 | -80 | 3*80 |
TQFN-3×3-20L
|
SIM I/F Swap
|
|||
| SGM6504 | (2:2)×4 | 1.8~5.5 | 400 | I/O | 12 | 3.5 | 12 | -80 | 2.5 |
TQFN-3×3-20L
|
4-2:2, Passive Swap
|
|
| SGM6505 | (1:2)×6 | 2~5 | 450 | I/O | 8.5 | 4.5 | 15 | 4/9 | -55 | 1.2 |
TSSOP-24,TQFN-4×4-24L
|
Six Channels 1:2 Multiplexer
|
| SGM6510 | 16×4 | 2.7~5.5 | 120 | I2C | 30 | 8 | 40 | -110 | 7 |
TSSOP-28,TQFN-4×4-28L
|
16×4, Passive
|
|
| SGM6511 | 16×8 | 2.7~5.5 | 120 | I2C | 30 | 8 | 50 | -110 | 7 |
TQFN-5×5-32L,LQFP-7×7-32L
|
16×8, Passive
|
|
| SGM6512 | 1:16 | 3.3~13.2 | 80 | I/O | 24 | 12 | 75 | 8/70 | -70 | 25 |
TQFN-5×5-32L,TSSOP-28
|
1:16, Multiplexer
|
| SGM6513 | (1:8)×2 | 3.3~13.2 | 135 | I/O | 24 | 12 | 50 | 8/36 | -70 | 25 |
TQFN-5×5-32L,TSSOP-28
|
Dual 1:8, Multiplexer
|
| SGM6514 | 16×8 | 2.7~5.5 | 250 | I2C | 30 | 8 | 50 | -110 | 7 |
LQFP-7×7-32L
|
High Speed, 16×8, Passive, I 2C Interface
|
|
| SGM6515 | 1:8 | 3.3~13.2 | 80 | I/O | 24 | 12 | 75 | 8/70 | -70 | 25 |
TSSOP-16
|
1:8, Multiplexer
|
| SGM6516 | 16×8 | 4.5~13.2 | 45 | I/O | 40 | 65 | 25 | -47 |
LQFP-10×10-44L
|
16×8, Passive
|
||
| SGM65231 | SPST×8 | 2.3~3.6 | 500 | I/O | 4.5 | 17.2 | 13.5 |
TQFN-4.5×3.5-20L,TSSOP-20
|
8-Bit SPST, Low Voltage, High Bandwidth Bus Switch
|
|||
| SGM65232 | (1:2)×32 | 3.3~5 | 100 | I/O | 11 | 26 | 13 | -60 |
LQFP-14×14-100L
|
High Speed, 32-Bit 2:1 Bus Multiplexer
|
||
| SGM6533 | (1:3)×3 | 2.5~5.5 | 350 | I/O | 7 | -60 |
TQFN-3×3-20L,TSSOP-20
|
High Speed, 3-1:3 Multiplexer
|
||||
| SGM7220 | Type C | 2.7~5 | I/O , I2C |
UTQFN-1.6×1.6-12L
|
USB Type-C Configuration, Channel Logic and Port Control
|
|||||||
| SGM7232 | (1:3)×2 | 2.7~4.3 | 380/400 | I/O | 4/9 | 18 | 7 | -90 |
UTQFN-2.2×1.4-12L
|
High Speed, 2-1:3 Multiplexer
|
||
| SGM7300A/B | 2:1 | 3.0~3.6 | 9000/12000 | I/O | 5 | 1.5 |
TLGA-2.5×4.5-20L
|
3.3V, Differential 2-Channel, 2:1 Multiplexer/Demultiplexer Switches
|
