NANO2 Quick Acting Subminiature Surface Mount Brick Ceramic Fuse 2A 250V 10.2mmx3.2mm

NANO2 Quick Acting Subminiature Surface Mount Brick Ceramic Fuse 2A 250V 10.2mmx3.2mm

Product Details:

Certification: UL,cUL
Model Number: R1032.1200

Payment & Shipping Terms:

Minimum Order Quantity: 2000 Pieces
Price: Negotiable
Packaging Details: Tape in reel,2000pcs per reel
Delivery Time: 1-2 Weeks
Payment Terms: T/T, Western Union
Supply Ability: 20,000,000 Pieces Per Month
Get Best Price Contact Now

Detail Information

Product Name: Ceramic Fuse Dimension: 10.2mmx3.2mm
Speed: F Plating: Gold Or Sliver
Rated Current: 2A Voltage Rating: 250V
High Light:

slow blow glass fuse

,

mini glass fuses

,

surface mount brick ceramic fuse

Product Description



NANO2 Gold Sliver Plated Quick Acting Subminiature Surface Mount Brick Ceramic Fuse 2A 250V 10.2mmx3.2mm





Description



The 250 NANO2 Fuse is a small square surface mount fuse that is designed to support higher voltage space sensitive applications. Enables compliance with the RoHS directive and is fully compatible with lead-free solder alloy and higher temperature profiles associated with lead-free assembly.

NANO2 Quick Acting Subminiature Surface Mount Brick Ceramic Fuse 2A 250V 10.2mmx3.2mm 0





Features

• 250 VAC voltage rating
• Fast-acting Fuse
• Available 0.50A – 5.00A
• RoHS Compliant
• Fully compatible with lead-free solder alloys and higher temperature profiles associated with lead-free assembly


Application

• AC/DC power adaptor
• Telecom equipment system power
• Portable system built-in AC/DC converter
• Lighting System
• LED Lighting





Specification



NANO2 Quick Acting Subminiature Surface Mount Brick Ceramic Fuse 2A 250V 10.2mmx3.2mm 1





Material



End cap

Au Plated Brass Cap

Body

Non-Transparent Square Ceramic Tube

Fuse element

Cu-Ag Alloy wire





Package



24mm Tape and Reel

EIA-RS 481-2 (IEC 286, part 3)

2000pcs per reel





Reliability Test



NO. Item Content Reference standards
1

Operating Temperature

-55°C to 125°C

IEC60068-2-1/2

2

Solderability

T=240°C±5°C , t=3sec±0.5sec,Coverage≥95%

MIL-STD-202, Method 208

3

Resistance to Soldering Heat

10 sec at 260°C

MIL-STD-202, Method 210, Test condition B

4

Insulation Resistance (after Opening)

10,000 ohms minimum

MIL-STD-202, Method 302, Test Condition A

5

Thermal Shock

5 cycles, -65°C / +125°C, 15 minutes at each extreme

MIL-STD-202, Method 107, Test Condition B

6

Mechanical Shock

100G’s peak for 6 milliseconds,3cycles

MIL-STD-202, Method 213, Test I

7

Vibration

0.03”amplitude, 10-55 Hz in 1 min. 2hrs each XYZ=6hrs

MIL-STD-202, Method 201

8

Moisture Resistance

10 cycles

MIL-STD-202, Method 106

9

Salt Spray

5% salt solution, 48hrs

MIL-STD-202, Method 101, Test

Condition B





Electrical Characteristics



Test Condition : All electrical test is to be conducted with the ambient air at a temperature of 25±5℃.

Interrupting Rating:Breaking Capacity: 50A@250Vac,200A@125Vac.

Operating Characteristics

Current Range

% of Ampere Rating(In)

Melting Time
0.05A-15A/20A-60A

100% * In

>4 Hour
0.05A-15A/20A-60A

200% * In

<60 sec
